Green Bank Solar Inverter 3KW MITS3KW 24volt
Green Bank Solar Inverter 3KW MITS3KW 24volt
Regular price
$895.00
Regular price
$975.00
Sale price
$895.00
Unit price
per
Couldn't load pickup availability
Green Bank Solar Inverter 3KW MITS3KW
- Pure sine wave 24v inverter
- Built-in MPPT solar charge controller
- Configurable input voltage range for home appliances and personal computers via LCD setting
- Configurable battery charging current based on applications via LCD setting
- Configurable AC/Solar Charge priority via LCD setting
- Compatible to mains voltage or generator power
- Auto restart while AC is recovering
- Overload / Over temperature /short circuit protection
- Inverter running without battery
- Lithium battery activation function.
- Cold start function
Specifications
| Model | MITS3KW |
| Related Output Power | 3000VA |
| Related Output Power | 3000W |
| Nominal DC Input Voltage | 24V |
| Input Voltage Waveform | Sinusoidal (utility or generator) |
| Nominal Input Voltage | 230Vac |
| Low Line Voltage Disconnect | 170Vac≥7V (UPS); 90Vac≥7V (Appliances) |
| Low Loss Voltage Re-connect | 180Vac≥7V (UPS); 100Vac≥7V (Appliances) |
| High line Voltage Disconnect | 280Vac≥7V |
| High line Voltage Re-Connect | 270Vac≥7V |
| Max AC Input Voltage | 280Vac |
| Nominal Input Frequency | 50Hz/60Hz (auto detection) |
| Low Line Frequency Disconnect | 40≥1Hz |
| Low Line Frequency Re-Connect | 42≥1Hz |
| High Line Frequency Disconnect | 65≥1Hz |
| High Line Frequency Re-Connect | 63≥1Hz |
| Output Voltage Waveform | As same as Input Waveform |
| Output Short Circuit Protection | Line Mode: Circuit Breaker |
| Efficiency (Line Mode) | >95% (Rated R load, battery full charged) |
| Transfer Time (Single Unit) | 10ms typical (UPS); 20ms typical (Appliances) |
| Transfer Time (Parallel) | 50ms typical (UPS) |
| Pass through without battery | Yes |
| Max Bypass overload current | 30A |
| Max Inverter/Rectifier Current | 15A/3000W |
